1.4 Ordering Information
1.4.1 Filter Configurator
Use the ordering number system to design an active filter according to the application requirements. For the VLT
®
Active
Filter AAF 006 Series, it is possible to order standard filters and filters with integral options by sending a type code string
describing the product to the local Danfoss sales office. For example: AAF006A190T4E21HXXGCXXXSXXXXAXBXCFXXXDX
This section describes each character in the type code. In the example, a standard 190 A active filter in an enclosure with
IP21 protection rating is selected for a 380–480 V net. The internet-based configurator configures the right filter for the right
application and generates a type code string. The configurator automatically generates an 8-digit sales number to be
delivered to the local sales office. It is also possible to establish a project list with several products and send it to a Danfoss
sales representative. The configurator can be found at www.danfoss.com/BusinessAreas/DrivesSolutions/.
1.4.2 Ordering Form Type Code
130BB504.10
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39
A FA x0 0 A T 4 E H x G C x x x x x x x B x C x x x x xDAS
Illustration 1.4 Type Code Example
Possible choice
Product groups 1-3 AAF
Series 4-6 006
Current rating 7-10 A190: 190 A
A250: 250 A
A310: 310 A
A400: 400 A
Phases 11 T: 3 Phases
Mains Voltage 12 4: 380–480 V AC
Enclosure 13-15 E21: IP21/Nema Type1
E54: IP54/Nema Type 12
E2M: IP21/Nema Type 1 with
mains shield
E5M: IP54/Nema Type 12 with
mains shield
RFI filter 16-17 HX: No RFI filter
H4: RFI filter, Class A1 (optional)
Display (LCP) 19 G: Graphical Local Control Panel
(LCP)
Coating PCB 20 C: Coated PCB
Mains option 21 X: No mains option
3: Mains disconnect and fuse
7: Fuse
Adaptation A 22 Reserved
Adaptation B 23 Reserved
Software release 24-27 Reserved
Software
language
28 Reserved
A options 29-30 AX: No A option
B options 31-32 BX: No B option
C-option configu-
ration
33-37 CFxxx: CO-option occupied with
active filter control card
D options 38-39 DO: 24 V back-up
DX: No options
Table 1.1 Type Code Definitions
176F3535 Backwall cooling kit for D14 (IP54)
176F3537 Backwall cooling kit for E1 (IP54)
Table 1.2 Optional Kits
Introduction
Operating Instructions
6 Danfoss A/S © 09/2014 All rights reserved. MG90V302
