6.12.7 16-** Data Readouts
Par.
No. #
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion index
Type
16-0* General Status
16-00 Control word 0 N/A All set-ups FALSE 0 V2
16-03 Status word 0 N/A All set-ups FALSE 0 V2
16-3* AF Status
16-30 DC link voltage 0 V All set-ups FALSE 0 Uint16
16-34 Heatsink temp. 0 °C All set-ups FALSE 100 Uint8
16-35 Inverter thermal 0 % All set-ups FALSE 0 Uint8
16-36 Inv. nom. current ExpressionLimit All set-ups FALSE -2 Uint32
16-37 Inv. max. current ExpressionLimit All set-ups FALSE -2 Uint32
16-39 Control card temp. 0 °C All set-ups FALSE 100 Uint8
16-40 Logging buffer full [0] No All set-ups TRUE - Uint8
16-49 Current fault source 0 N/A All set-ups TRUE 0 Uint8
16-6* Inputs & Outputs
16-60 Digital input 0 N/A All set-ups FALSE 0 Uint16
16-66 Digital output [bin] 0 N/A All set-ups FALSE 0 Int16
16-71 Relay output [bin] 0 N/A All set-ups FALSE 0 Int16
16-8* Fieldbus & FC Port
16-80 Fieldbus CTW 1 0 N/A All set-ups FALSE 0 V2
16-84 Comm. option STW 0 N/A All set-ups FALSE 0 V2
16-85 FC port CTW 1 0 N/A All set-ups FALSE 0 V2
16-9* Diagnosis Readouts
16-90 Alarm word 0 N/A All set-ups FALSE 0 Uint32
16-91 Alarm word 2 0 N/A All set-ups FALSE 0 Uint32
16-92 Warning word 0 N/A All set-ups FALSE 0 Uint32
16-93 Warning word 2 0 N/A All set-ups FALSE 0 Uint32
16-94 Ext. status word 0 N/A All set-ups FALSE 0 Uint32
Applications and Basic Prog... Operating Instructions
MG90V302 Danfoss A/S © 09/2014 All rights reserved. 67
6 6
