6.2.6 Main Menu Mode
The LCP provides access to the Main Menu mode. Select
the Main Menu mode by pressing the [Main Menu] key.
The resulting readout appears on the display of the LCP.
Lines 2 through 5 on the display show a list of parameter
groups that can be selected via the ▲ and ▼ keys.
Each parameter has a name and number that remain the
same regardless of the programming mode. In the Main
Menu mode, the parameters are divided into groups. The
first digit of the parameter number (from the left) indicates
the parameter group number. All parameters can be
changed in the main menu. Option cards added to the
unit enable additional parameters associated with the
option device.
6.2.7 Parameter Selection
Select a parameter group with the navigation keys.
The following parameter groups are accessible:
Group Title Function
0-** Operation/Display Parameters related to the fundamental functions of the filter, function of the LCP
keys and configuration of the LCP display.
5-** Digital In/Out Parameter group for configuring the digital inputs and outputs.
8-** Communication and Options Parameter group for configuring communications and options.
14-** Special Functions Parameter group for configuring special filter functions.
15-** Unit Information Parameter group containing filter information such as operating data, hardware
configuration, and software versions.
16-** Data Readouts Parameter group for data readouts, e.g. actual references, voltages, control, alarm,
warning, and status words.
300-** AF Settings Parameter group for setting the active filter.
301-** AF Readouts Parameter group for the filter readouts.
Table 6.5 Parameter Groups
After selecting a parameter group, select a parameter with the navigation keys.
The middle section on the LCP display shows the parameter number and name as well as the selected parameter value.
Applications and Basic Prog... Operating Instructions
40 Danfoss A/S © 09/2014 All rights reserved. MG90V302
