8-06 Reset Control Word Timeout
This parameter is active only when [0] Hold set-up has been
selected in parameter 8-05 End-of-Timeout Function.
Option: Function:
performs the reset and then immediately
reverts to the [0] Do not reset setting
6.6.2 8-3* FC Port Settings
8-30 Protocol
Option: Function:
[0] * FC Communication according to the FC Protocol.
[1] FC MC Select the protocol for the FC (standard) port.
[2] Modbus RTU
8-31 Address
Range: Function:
Size related* [ 1 - 255 ] Enter the address for the FC (standard)
port.
Valid range: 1-126.
8-32 FC Port Baud Rate
Option: Function:
[0] 2400 Baud Baud rate selection for the FC (standard) port.
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
8-35 Minimum Response Delay
Range: Function:
10 ms* [ 1 - 10000
ms]
Specify the minimum delay time
between receiving a request and
transmitting a response. This is used for
overcoming modem turnaround delays.
8-36 Max Response Delay
Range: Function:
Size
related*
[ 11 -
10001 ms]
Specify the maximum permissible
delay time between transmitting a
request and receiving a response. If a
response from the frequency converter
is exceeding the time setting, then it is
discarded.
8-37 Max Inter-Char Delay
Range: Function:
Size
related*
[ 0.00 -
35.00 ms]
Specify the maximum permissible time
interval between receipt of 2 bytes. This
8-37 Max Inter-Char Delay
Range: Function:
parameter activates timeout if
transmission is interrupted.
This parameter is active only when
parameter 8-30 Protocol is set to [1] FC MC
protocol.
8-53 Start Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the unit start function via the
terminals (digital input) and/or via the fieldbus.
[0] Digital
input
Activates a start command via a digital input.
[1] Bus Activates a start command via the serial
communication port or Fieldbus option.
[2] Logic
AND
Activates a start command via the fieldbus/serial
communication port, AND additionally via one of
the digital inputs.
[3]
*
Logic
OR
Activates a start command via the fieldbus/serial
communication port OR via one of the digital
inputs.
8-55 Set-up Select
Option: Function:
NOTICE
This parameter is active only when
parameter 8-01 Control Site is set to [0]
Digital and control word.
Select control of the unit set-up selection via the
terminals (digital input) and/or via the fieldbus.
[0] Digital
input
Activates the set-up selection via a digital input.
[1] Bus Activates the set-up selection via the serial
communication port or fieldbus option.
[2] Logic
AND
Activates the set-up selection via the fieldbus/
serial communication port, AND additionally via
one of the digital inputs.
[3] * Logic
OR
Activate the set-up selection via the fieldbus/
serial communication port OR via one of the
digital inputs.
Applications and Basic Prog... Operating Instructions
MG90V302 Danfoss A/S © 09/2014 All rights reserved. 49
