Number Description Warning Alarm/Trip Alarm/Trip Lock Parameter Reference
79 Illegal PS config X X
80 Unit initialised to default value X
250 New spare part X
251 New type code X X
300 Mains cont. fault X
301 SC cont. fault X
302 Cap. over current X X
303 Cap. earth fault X X
304 DC over current X X
305 Mains freq. limit X
306 Compensation Limit
308 Resistor temp X X
309 Mains earth fault X X
311 Switch. freq. limit X
312 CT range X
314 Auto CT interrupt X
315 Auto CT error X
316 CT location error X
317 CT polarity error X
318 CT ratio error X
Table 8.1 Alarm/Warning Code List
A trip is the action when an alarm has appeared. The trip disables the active filter and can be reset by pressing [Reset] or
resetting via a digital input (parameter group 5-1* Digital Inputs [1] Reset). The origin event that caused an alarm cannot
damage the active filter or cause dangerous conditions. A trip lock is an action when an alarm occurs, which may cause
damage to active filter or connected parts. A trip lock situation can only be reset by a power cycling.
Warning
yellow
Alarm flashing red
Trip locked yellow and red
Table 8.2 LED Indicator Lights
Maintenance, Diagnostics an... Operating Instructions
MG90V302 Danfoss A/S © 09/2014 All rights reserved. 77
