Danfoss VLT AQUA Drive FC 202 Operating Instructions

Mains Supply 1x 380 VAC - Normal overload 110% for 1 minute Frequency converter Typical Shaft Output [kW]
P7K5
7.5
P11K P22K P37K
Typical Shaft Output [HP] at 460 V 10 15 30 50 IP 21 / NEMA 1 B1 B2 C1 C2 IP 55 / NEMA 12 B1 B2 C1 C2
IP 66
B1 B2 C1 C2
Output current
Continuous (3 x 380-440 V) [A]
16 24 44 73
Intermittent (3 x 380-440 V) [A]
17.6 26.4 48.4 80.3
Continuous (3 x 441-480 V) [A]
14.5 21 40 65
Intermittent (3 x 441-480 V) [A]
15.4 23.1 44 71.5
Continuous kVA (400 V AC) [kVA]
11.0 16.6 30.5 50.6
Continuous kVA (460 V AC) [kVA]
11.6 16.7 31.9 51.8
Max. cable size:
(mains, motor, brake) [[mm
2
/ AWG]
2)
10/7 35/2 50/1/0 120/4/0
Max. input current
Continuous (1 x 380-440 V ) [A]
33 48 94 151
Intermittent (1 x 380-440 V ) [A]
36 53 103 166
Continuous (1 x 441-480 V) [A]
30 41 85 135
Intermittent (1 x 441-480 V) [A]
33 46 93 148
Max. pre-fuses
1)
[A]
63 80 160 250
Environment
Estimated power loss at rated max. load [W]
4)
300 440 880 1480
Weight enclosure IP 21 [kg] 23 27 45 65
Weight enclosure IP 55 [kg] 23 27 45 65
Weight enclosure IP 66 [kg] 23 27 45 65
Efficiency
3)
0.96 0.96 0.96 0.96
10.1.3. Mains Supply 1 x 380 - 480 VAC
VLT
®
AQUA Drive
Operating Instructions
10. Specifications
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark 151
10
