Danfoss VLT AQUA Drive FC 202 Operating Instructions

[2581] Pump Status Status for the operation of each individual pump controlled by the Cascade Controller
NB!
Please consult the VLT
®
AQUA Drive Programming Guide, MG.20.OX.YY for detailed information.
0-21 Display Line 1.2 Small
Option: Function:
Select a variable for display in line 1, middle position.
[1662] * Analog input 53 The options are the same as those listed for par. 0-20
Display Line 1.1 Small .
0-22 Display Line 1.3 Small
Option: Function:
Select a variable for display in line 1, right position.
[1614] * Motor Current The options are the same as those listed for par. 0-20
Display Line 1.1 Small .
0-23 Display Line 2 Large
Option: Function:
Select a variable for display in line 2. The options are the same as those listed for par. 0-20 Display
Line 1.1 Small
.
[1615] * Frequency
0-24 Display Line 3 Large
Option: Function:
[1652] * Feedback [Unit] Select a variable for display in line 2. The options are the same as those listed for par. 0-20 Display
Line 1.1 Small
.
0-37 Display Text 1
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 1 in par. 0-20 Dis-
play
Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small , par.
0-23 Display
Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the LCP to
change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is highlighted
by the cursor, it can be changed. Use the
▲
or
▼
buttons on the LCP to change a character. A
character can be inserted by placing the cursor between two characters and pressing
▲
or
▼
.
0-38 Display Text 2
Range: Function:
0 N/A* [0 - 0 N/A] In this parameter it is possible to write an individual text string for display in the LCP or to be read
via serial communication. If to be displayed permanently select Display Text 2 in par. 0-20 Dis-
play
Line 1.1 Small , par. 0-21 Display Line 1.2 Small , par. 0-22 Display Line 1.3 Small , par.
0-23 Display
Line 2 Large or par. 0-24 Display Line 3 Large . Use the
▲
or
▼
buttons on the LCP to
change a character. Use the
◀
and
▶
buttons to move the cursor. When a character is highlighted
by the cursor, this character can be changed. A character can be inserted by placing the cursor
between two characters and pressing
▲
or
▼
.
VLT
®
AQUA Drive
Operating Instructions
8. How to programme the frequency converter
MG.20.M5.02 - VLT
®
is a registered Danfoss trademark 73
8
