5-53 Term. 29 High Ref./Feedb. Value
Range: Function:
100.000 N/
A*
[-999999.999 - 999999.999 N/A] Enter the high reference value [RPM] for the motor shaft speed and the high feedback value, see
also par. 5-58 Term.
33 High Ref./Feedb. Value .
8.2.8. 6-** Analog In/Out
Parameter group for configuration of the analog input and output.
6-00 Live Zero Timeout Time
Range: Function:
10 s* [1 - 99 s] Enter the Live Zero Time-out time period. Live Zero Time-out Time is active for analog inputs, i.e.
terminal 53 or terminal 54, allocated to current and used as reference or feedback sources. If the
reference signal value associated with the selected current input falls below 50% of the value set
in par. 6-10
Terminal 53 Low Voltage , par. 6-12 Terminal 53 Low Current , par. 6-20 Terminal 54
Low Voltage
or par. 6-22 Terminal 54 Low Current for a time period longer than the time set in par.
6-00
Live Zero Timeout Time , the function selected in par. 6-01 Live Zero Timeout Function will be
activated.
6-01 Live Zero Timeout Function
Option: Function:
Select the time-out function. The function set in par. 6-01 Live Zero Timeout Function will be acti-
vated if the input signal on terminal 53 or 54 is below 50% of the value in par. 6-10
Terminal 53
Low Voltage
, par. 6-12 Terminal 53 Low Current , par. 6-20 Terminal 54 Low Voltage or par.
6-22 Terminal
54 Low Current for a time period defined in par. 6-00 Live Zero Timeout Time . If
several time-outs occur simultaneously, the frequency converter prioritises the time-out functions
as follows:
1. par. 6-01
Live Zero Timeout Function
2. par. 8-04 Control Timeout Function
The output frequency of the frequency converter can be:
• [1] frozen at the present value
• [2] overruled to stop
• [3] overruled to jog speed
• [4] overruled to max. speed
• [5] overruled to stop with subsequent trip
If you select set-up 1-4, par. 0-10 Active
Set-up must be set to Multi Set-up , [9].
This parameter cannot be adjusted while the motor is running.
[0] * Off
[1] Freeze output
[2] Stop
[3] Jogging
[4] Max. speed
[5] Stop and trip
8. How to programme the frequency converter
VLT
®
AQUA Drive
Operating Instructions
90 MG.20.M5.02 - VLT
®
is a registered Danfoss trademark
8
