6-41 Term. X30/12 High Voltage
Range: Function:
10.0V
*
[Par. 6-40 to 10.0 V] Sets the analog input scaling value to correspond to the high
reference/feedback value set in par. 6-45.
6-44 Term. X30/12 Low Ref./Feedb. Value
Range: Function:
0.000
Unit
*
[-1000000.000 to par.
6-45]
Sets the analog input scaling value to correspond to the low
voltage value set in par. 6-44.
6-45 Term. X30/12 High Ref./Feedb. Value
Range: Function:
1500.00
0 Unit
*
[Par. 6-44 to
1000000.000]
Sets the analog input scaling value to correspond to the high
voltage value set in par. 6-41.
6-46 Term. X30/12 Filter Time Constant
Range: Function:
0.001s
*
[0.001 - 10.000 s]
A 1
st
order digital low pass filter time constant for suppressing
electrical noise on terminal X30/12.
Par. 6-46 cannot be changed while the motor is running.
6-47 Term. X30/12 Live Zero
Option: Function:
This parameter makes it possible to disable the Live Zero mon-
itoring. E.g. to be used if the analog outputs are used as part of
a decentral I/O system (e.g. when not part of any frequency
converter related control functions, but feeding an external con-
trol system with data)
[0]
*
Disabled
[1] Enabled
2.8.8. 6-5* Analog Output 1
Parameters for configuring the scaling and limits for analog output 1, i.e. Terminal 42. Analog
outputs are current outputs: 0/4 – 20 mA. Common terminal (terminal 39) is the same terminal
and has the same electrical potential for analog common and digital common connection. Reso-
lution on analog output is 12 bit.
6-50 Terminal 42 Output
Range: Function:
Select the function of Terminal 42 as an analog current output.
0[No operation]
[100]
*
Output frequency
[101] Reference
[102] Feedback
[103] Motor current
2. Parameter Description VLT
®
AQUA Drive Programming Guide
102
