10-11 Process Data Config Write
Option: Function:
Select the process write data for I/O Assembly Instances
101/151. Elements [2] and [3] of this array can be selected.
Elements [0] and [1] of the array are fixed.
[0]
*
None
[3-02 ] Minimum reference
[3-03 ] Maximum reference
[3-41 ] Ramp 1 ramp up time
[3-42 ] Ramp 1 ramp down
time
[3-51 ] Ramp 2 ramp up time
[3-52 ] Ramp 2 ramp down
time
[3-80 ] Jog ramp time
[3-81 ] Quick stop ramp time
[4-11 ] Motor speed low limit
(RPM)
[4-13 ] Motor speed high limit
(RPM)
[4-16 ] Torque limit motor
mode
[4-17 ] Torque limit genera-
tor mode
[5-90 ] Digital & Relay Bus
Control
[5-93 ] Pulse Out #27 Bus
Control
[5-95] Pulse Out #29 Bus
Control
[6-53 ] Terminal 42 Output
Bus Control
[8-90 ] Bus Jog 1 Speed
[8-91 ] Bus Jog 2 Speed
[16-80] Fieldbus CTW 1
(Fixed)
[16-82 ] Fieldbus REF 1 (Fixed)
10-12 Process Data Config Read
Option: Function:
Select the process read data for I/O Assembly Instances
101/151. Elements [2] and [3] of this array can be selected.
Elements [0] and [1] of the array are fixed.
None
[16-00 ] Control Word
[16-01 ] Reference [Unit]
[16-02 ] Reference %
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 127
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
