Danfoss vlt aqua Programming Guide

[16-03 ] Status Word (Fixed)
[16-05 ] Main Actual Value (%)
(Fixed)
[16-10 ] Power [kW]
[16-11 ] Power [hp]
[16-12 ] Motor Voltage
[16-13 ] Frequency
[16-14 ] Motor Current
[16-15 ] Frequency [%]
[16-16 ] Torque
[16-17 ] Speed [RPM]
[16-18 ] Motor Thermal
[16-22 ] Torque [%]
[16-30 ] DC Link Voltage
[16-32 ] BrakeEnergy/s
[16-33 ] BrakeEnergy/2 min
[16-34 ] Heatsink Temp.
[16-35 ] Inverter Thermal
[16-38 ] SL Control State
[16-39] Controlcard Temp.
[16-50 ] External Reference
[16-52 ] Feedback [Unit]
[16-53 ] Digi Pot Reference
[16-54] Feedback 1 [Unit]
[16-55 ] Feedback 2 [Unit]
[16-56 ] Feedback 3 [Unit]
[16-60 ] Digital Input
[16-61 ] Terminal 53 Switch
Setting
[16-62 ] Analog Input 53
[16-63 ] Terminal 54 Switch
Setting
[16-64 ] Analog Input 54
[16-65 ] Analog Output 42
[mA]
[16-66 ] Digital Output [bin]
[16-67 ] Freq. Input #29 [Hz]
[16-68 ] Freq. Input #33 [Hz]
[16-69 ] Pulse Output #27
[Hz]
[16-70 ] Pulse Output #29
[Hz]
[16-71 ] Relay Output [bin]
[16-75 ] Analog In X30/11
[16-76 ] Analog In X30/12
[16-77 ] Analog Out X30/8
[mA]
2. Parameter Description VLT
®
AQUA Drive Programming Guide
128 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
