Danfoss vlt aqua Programming Guide

[16-84 ] Comm Option STW
[16-85 ] FC Port CTW 1
[16-90] Alarm Word
[16-91 ] Alarm Word 2
[16-92 ] Warning Word
[16-93 ] Warning Word 2
[16-94 ] Extended Status
Word
[16-95 ] Extended Status
Word 2
[16-96 ] Prev. Maintenance
Word
10-13 Warning Parameter
Range: Function:
0
*
[0 - 65535] View a DeviceNet-specific Warning word. One bit is assigned to
every warning. Please refer to the DeviceNet Operating Instruc-
tions (MG.33.DX.YY) for further information.
Bit: Meaning:
0 Bus not active
1 Explicit connection timeout
2 I/O connection
3 Retry limit reached
4 Actual is not updated
5CAN bus off
6 I/O send error
7 Initialization error
8 No bus supply
9Bus off
10 Error passive
11 Error warning
12 Duplicate MAC ID Error
13 RX queue overrun
14 TX queue overrun
15 CAN overrun
10-14 Net Reference
Read only from LCP.
Select the reference source in Instance 21/71 and 20/70.
[0]
*
Off Enables reference via analog/digital inputs.
[1] On Enables reference via the fieldbus.
10-15 Net Control
Read only from LCP.
Select the control source in Instance 21/71 and 20-70.
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 129
