[0]
*
Off Enables control via analog/digital inputs.
[1] On enable control via the fieldbus.
2.11.4. 10-2* COS Filters
Parameters for configuring COS filter settings.
10-20 COS Filter 1
Range: Function:
FFFF
*
[0 - FFFF] Enter the value for COS Filter 1 to set up the filter mask for the
Status Word. When operating in COS (Change-Of-State), this
function filters out bits in the Status Word that should not be
sent if they change.
10-21 COS Filter 2
Range: Function:
FFFF
*
[0 - FFFF] Enter the value for COS Filter 2, to set up the filter mask for the
Main Actual Value. When operating in COS (Change-Of-State),
this function filters out bits in the Main Actual Value that should
not be sent if they change.
10-22 COS Filter 3
Range: Function:
FFFF
*
[0 - FFFF] Enter the value for COS Filter 3, to set up the filter mask for PCD
3. When operating in COS (Change-Of-State), this function fil-
ters out bits in PCD 3 that should not be sent if they change.
10-23 COS Filter 4
Range: Function:
FFFF
*
[0 - FFFF] Enter the value for COS Filter 4 to set up the filter mask for PCD
4. When operating in COS (Change-Of-State), this function fil-
ters out bits in PCD 4 that should not be sent if they change.
2.11.5. 10-3* Parameter Access
Parameter group providing access to indexed parameters and defining programming set-up.
10-30 Array Index
Range: Function:
0
*
[0 - 255] View array parameters. This parameter is valid only when a De-
viceNet fieldbus is installed.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
130
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
