[40] Drive Stopped This event is TRUE if the frequency converter is stopped or
coasted by any means (either via digital input, fieldbus or other).
[41] Reset Trip This event is TRUE if the frequency converter is tripped (but not
trip-locked) and the reset button is pressed.
[42] Auto Reset Trip This event is TRUE if the frequency converter is tripped (but not
trip-locked) and an Automatic Reset is issued.
[43] OK Key This event is TRUE if the OK key on the LCP is pressed.
[44] Reset This event is TRUE if the Reset key on the LCP is pressed.
[45] Left Key This event is TRUE if the Left key on the LCP is pressed.
[46] Right Key This event is TRUE if the Right key on the LCP is pressed.
[47] Up Key This event is TRUE if the Up key on the LCP is pressed.
[48] Down Key This event is TRUE if the Down key on the LCP is pressed.
[50] Comparator 4 Use the result of comparator 4 in the logic rule.
[51] Comparator 5 Use the result of comparator 5 in the logic rule.
[60] Logic Rule 4 Use the result of logic rule 4 in the logic rule.
[61] Logic Rule 5 Use the result of logic rule 5 in the logic rule.
13-02 Stop Event
Option: Function:
Select the boolean (TRUE or FALSE) input to deactivate Smart
Logic Control.
[0]
*
False Enters the fixed value of FALSE in the logic rule.
[1] True Enters the fixed value TRUE in the logic rule.
[2] Running See parameter group 5-3* for further description.
[3] In range See parameter group 5-3* for further description.
[4] On reference See parameter group 5-3* for further description.
[5] Torque limit See parameter group 5-3* for further description.
[6] Current limit See parameter group 5-3* for further description.
[7] Out of current range See parameter group 5-3* for further description.
[8] Below I
LOW
See parameter group 5-3* for further description.
[9] Above I
HIGH
See parameter group 5-3* for further description.
[10] Out of speed range
[11] Below speed low See parameter group 5-3* for further description.
[12] Above speed high See parameter group 5-3* for further description.
[13] Out of feedb. range See parameter group 5-3* for further description.
[14] Below feedb. low See parameter group 5-3* for further description.
[15] Above feedb. high See parameter group 5-3* for further description.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
134
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
