[48] Down Key This event is TRUE if the Down key on the LCP is pressed.
[50] Comparator 4 Use the result of comparator 4 in the logic rule.
[51] Comparator 5 Use the result of comparator 5 in the logic rule.
[60] Logic rule 4 Use the result of logic rule 4 in the logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic rule.
13-03 Reset SLC
Option: Function:
[0]
*
Do not reset SLC Retains programmed settings in all group 13 parameters (13-*).
[1] Reset SLC Resets all group 13 parameters (13-*) to default settings.
2.12.3. 13-1* Comparators
Comparators are used for comparing continuous variables (i.e. output frequency, output current,
analog input etc.) to fixed preset values. In addition, there are digital values that will be compared
to fixed time values. See explanation in par. 13-10. Comparators are evaluated once in each scan
interval. Use the result (TRUE or FALSE) directly. All parameters in this parameter group are array
parameters with index 0 to 5. Select index 0 to programme Comparator 0, select index 1 to pro-
gramme Comparator 1, and so on.
13-10 Comparator Operand
Array [4]
Select the variable to be monitored by the comparator.
[0]
*
DISABLED
[1] Reference
[2] Feedback
[3] Motor speed
[4] Motor current
[5] Motor torque
[6] Motor power
[7] Motor voltage
[8] DC-link voltage
[9] Motor thermal
[10] Drive thermal
[11] Heat sink temp.
[12] Analog input AI53
2. Parameter Description VLT
®
AQUA Drive Programming Guide
136
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
