[13] Analog input AI54
[14] Analog input AIFB10
[15] Analog input AIS24V
[17] Analog input AICCT
[18] Pulse input FI29
[19] Pulse input FI33
[20] Alarm number
[30] Counter A
[31] Counter B
13-11 Comparator Operator
Array [6]
For par. 13-10 containing values from [0] to [31] the following
is valid:
Select the operator to be used in the comparison.
[0] < Select
<
[0] for the result of the evaluation to be TRUE, when
the variable selected in par. 13-10 is smaller than the fixed value
in par. 13-12. The result will be FALSE, if the variable selected
in par. 13-10 is greater than the fixed value in par. 13-12.
[1]
*
≈ Select
≈
[1] for the result of the evaluation to be TRUE, when
the variable selected in par. 13-10 is approximately equal to the
fixed value in par. 13-12.
[2] > Select
>
[2] for the inverse logic of option
<
[0].
13-12 Comparator Value
Array [6]
0.000
*
[-100000.000 -
100000.000]
Enter the ‘trigger level’ for the variable that is monitored by this
comparator. This is an array parameter containing comparator
values 0 to 5.
2.12.4. 13-2* Timers
This parameter group consists of timer parameters.
Use the result (TRUE or FALSE) from
timers
directly to define an
event
(see par. 13-51), or as
boolean input in a
logic rule
(see par. 13-40, 13-42 or 13-44). A timer is only FALSE when started
by an action (i.e. Start timer 1 [29]) until the timer value entered in this parameter is elapsed.
Then it becomes TRUE again.
All parameters in this parameter group are array parameters with index 0 to 2. Select index 0 to
program Timer 0, select index 1 to program Timer 1, and so on.
13-20 SL Controller Timer
Array [3]
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
137
2
