0.00 s *
[0.00 - 360000.00 s] Enter the value to define the duration of the FALSE output from
the programmed timer. A timer is only FALSE if it is started by
an action (i.e.
Start timer 1 [29]) and until the given timer value
has elapsed.
2.12.5. 13-4* Logic Rules
Combine up to three boolean inputs (TRUE / FALSE inputs) from timers, comparators, digital in-
puts, status bits and events using the logical operators AND, OR, and NOT. Select boolean inputs
for the calculation in par. 13-40, 13-42, and 13-44. Define the operators used to logically combine
the selected inputs in par. 13-41 and 13-43.
Priority of calculation
The results of par. 13-40, 13-41, and 13-42 are calculated first. The outcome (TRUE / FALSE) of
this calculation is combined with the settings of par. 13-43 and 13-44, yielding the final result
(TRUE / FALSE) of the logic rule.
13-40 Logic Rule Boolean 1
Array [6]
Select the first boolean (TRUE or FALSE) input for the selected
logic rule.
[0]
*
False Enters the fixed value of FALSE in the logic rule.
[1] True Enters the fixed value TRUE in the logic rule.
[2] Running See parameter group 5-3* for further description.
[3] In range See parameter group 5-3* for further description.
[4] On reference See parameter group 5-3* for further description.
[5] Torque limit See parameter group 5-3* for further description.
[6] Current limit See parameter group 5-3* for further description.
[7] Out of current range See parameter group 5-3* for further description.
[8] Below I
LOW
See parameter group 5-3* for further description.
[9] Above I
HIGH
See parameter group 5-3* for further description.
[10] Out of speed range
[11] Below speed low See parameter group 5-3* for further description.
[12] Above speed high See parameter group 5-3* for further description.
[13] Out of feedb. range See parameter group 5-3* for further description.
[14] Below feedb. low See parameter group 5-3* for further description.
[15] Above feedb. high See parameter group 5-3* for further description.
[16] Thermal warning See parameter group 5-3* for further description.
[17] Mains out of range See parameter group 5-3* for further description.
[18] Reversing See parameter group 5-3* for further description.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
138 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
