[19] Warning See parameter group 5-3* for further description.
[20] Alarm (trip) See parameter group 5-3* for further description.
[21] Alarm (trip lock) See parameter group 5-3* for further description.
[22] Comparator 0 Use the result of comparator 0 in the logic rule.
[23] Comparator 1 Use the result of comparator 1 in the logic rule.
[24] Comparator 2 Use the result of comparator 2 in the logic rule.
[25] Comparator 3 Use the result of comparator 3 in the logic rule.
[26] Logic rule 0 Use the result of logic rule 0 in the logic rule.
[27] Logic rule 1 Use the result of logic rule 1 in the logic rule.
[28] Logic rule 2 Use the result of logic rule 2 in the logic rule.
[29] Logic rule 3 Use the result of logic rule 3 in the logic rule.
[30] Time-out 0 Use the result of timer 0 in the logic rule.
[31] Time-out 1 Use the result of timer 1 in the logic rule.
[32] Time-out 2 Use the result of timer 2 in the logic rule.
[33] Digital input DI18 Use the value of DI18 in the logic rule (High = TRUE).
[34] Digital input DI19 Use the value of DI19 in the logic rule (High = TRUE).
[35] Digital input DI27 Use the value of DI27 in the logic rule (High = TRUE).
[36] Digital input DI29 Use the value of DI29 in the logic rule (High = TRUE).
[37] Digital input DI32 Use the value of DI32 in the logic rule (High = TRUE).
[38] Digital input DI33 Use the value of DI33 in the logic rule (High = TRUE).
[39] Start command This logic rule is TRUE if the frequency converter is started by
any means (either via digital input, field bus or other).
[40] Drive Stopped This logic rule is TRUE if the frequency converter is stopped or
coasted by any means (either via digital input, fieldbus or other).
[41] Reset Trip This logic rule is TRUE if the frequency converter is tripped (but
not trip-locked) and the reset button is pressed.
[42] Auto Reset Trip This logic rule is TRUE if the frequency converter is tripped (but
not trip-locked) and an Automatic Reset is issued.
[43] OK Key This logic rule is TRUE if the OK key on the LCP is pressed.
[44] Reset Key This logic rule is TRUE if the Reset key on the LCP is pressed.
[45] Left Key This logic rule is TRUE if the Left key on the LCP is pressed.
[46] Right Key This logic rule is TRUE if the Right key on the LCP is pressed.
[47] Up Key This logic rule is TRUE if the Up key on the LCP is pressed.
[48] Down Key This logic rule is TRUE if the Down key on the LCP is pressed.
[50] Comparator 4 Use the result of comparator 4 in the logic rule.
[51] Comparator 5 Use the result of comparator 5 in the logic rule.
