Danfoss vlt aqua Programming Guide

[60] Logic rule 4 Use the result of logic rule 4 in the logic rule.
[61] Logic rule 5 Use the result of logic rule 5 in the logic rule.
[70] SL Time-out 3 Use the result of timer 3 in the logic rule.
[71] SL Time-out 4 Use the result of timer 4 in the logic rule.
[72] SL Time-out 5 Use the result of timer 5 in the logic rule.
[73] SL Time-out 6 Use the result of timer 6 in the logic rule.
[74] SL Time-out 7 Use the result of timer 7 in the logic rule.
13-41 Logic Rule Operator 1
Array [6]
Select the first logical operator to use on the Boolean inputs
from par. 13-40 and 13-42.
[13 -XX] signifies the boolean input of par. 13-*.
[0]
*
DISABLED Ignores par. 13-42, 13-43, and 13-44.
[1] AND evaluates the expression [13-40] AND [13-42].
[2] OR evaluates the expression [13-40] OR [13-42].
[3] AND NOT evaluates the expression [13-40] AND NOT [13-42].
[4] OR NOT evaluates the expression [13-40] OR NOT [13-42].
[5] NOT AND evaluates the expression NOT [13-40] AND [13-42].
[6] Not or evaluates the expression NOT [13-40] OR [13-42].
[7] Not and not evaluates the expression NOT [13-40] AND NOT [13-42].
[8] Not or not evaluates the expression NOT [13-40] OR NOT [13-42].
13-42 Logic Rule Boolean 2
Array [6]
Select the second boolean (TRUE or FALSE) input for the selec-
ted logic rule.
See Parameter 13-40 for further descriptions of choices and
their functions.
13-43 Logic Rule Operator 2
Array [6]
2. Parameter Description VLT
®
AQUA Drive Programming Guide
140 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
