Danfoss vlt aqua Programming Guide

16-82 Fieldbus REF 1
Range: Function:
0
*
[-200 - 200] View the two-byte word sent with the control word form the
Bus-Master to set the reference value.
For more information please refer to the relevant fieldbus man-
ual.
16-84 Comm. Option STW
Range: Function:
0
*
[0 - 65535] View the extended fieldbus comm. option status word.
For more information please refer to the relevant fieldbus man-
ual.
16-85 FC Port CTW 1
Range: Function:
0
*
[0 - 65535] View the two-byte Control word (CTW) received from the Bus-
Master. Interpretation of the control word depends on the field-
bus option installed and the Control word profile selected in par.
8-10.
16-86 FC Port REF 1
Range: Function:
0
*
[0 - 0] View the two-byte Status word (STW) sent to the Bus-Master.
Interpretation of the Status word depends on the fieldbus option
installed and the Control word profile selected in par. 8-10.
2.15.8. 16-9* Diagnosis Read-Out
Parameters displaying alarm, warning and extended status words.
16-90 Alarm Word
Range: Function:
0
*
[0 - FFFFFFFF] View the alarm word sent via the serial communication port in
hex code.
16-91 Alarm Word 2
Range: Function:
0
*
[0 - FFFFFFFF] View the alarm word 2 sent via the serial communication port
in hex code.
16-92 Warning Word
Range: Function:
0
*
[0 - FFFFFFFF] View the warning word sent via the serial communication port
in hex code.
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark 169
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
