Danfoss vlt aqua Programming Guide

16-72 Counter A
Range: Function:
0
*
[0 - 0] View the present value of Counter A. Counters are useful as
comparator operands, see par. 13-10.
The value can be reset or changed either via digital inputs (pa-
rameter group 5-1*) or by using an SLC action (par. 13-52).
16-73 Counter B
Range: Function:
0
*
[0 - 0] View the present value of Counter B. Counters are useful as
comparator operands (par. 13-10).
The value can be reset or changed either via digital inputs (pa-
rameter group 5-1*) or by using an SLC action (par. 13-52).
16-74 Precise Stop Counter
Range: Function:
0
*
[-2147483648 -
2147483648]
Returns the actual counter value of precise counter (par. 1-84).
16-75 Analog In X30/11
Range: Function:
0.000
*
[0.000 - 0.000] View the actual value at input X30/11 of MCB 101.
16-76 Analog In X30/12
Range: Function:
0.000
*
[0.000 - 0.000] View the actual value at input X30/12 of MCB 101.
16-77 Analog Out X30/8 16-77 [mA]
Range: Function:
0.000
*
[0.000 - 0.000] View the actual value at input X30/8 in mA.
2.15.7. 16-8* Fieldbus & FC Port
Parameters for reporting the BUS references and control words.
16-80 Fieldbus CTW 1
Range: Function:
0
*
[0 - 65535] View the two-byte Control word (CTW) received from the Bus-
Master. Interpretation of the Control word depends on the
fieldbus option installed and the Control word profile selected in
par. 8-10.
For more information please refer to the relevant fieldbus man-
ual.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
168 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
