Danfoss vlt aqua Programming Guide

2.18.5. 21-3* Closed Loop 2 Ref/Fb
Configure Extended Closed Loop 2 Controller reference and feedback.
21-30 Ext. 2 Ref./Feedback Unit
Option: Function:
See par. 21-10,
Ext. 1 Ref/Feedback Unit , for details
21-31 Ext. 2 Minimum Reference
Option: Function:
See par. 21-11,
Ext. 1 Minimum Reference , for details.
21-32 Ext. 2 Maximum Reference
Option: Function:
See par. 21-12,
Ext. 1 Maximum Reference , for details.
21-33 Ext. 2 Reference Source
Option: Function:
See par. 21-13,
Ext. 1 Reference Source , for details.
21-34 Ext. 2 Feedback Source
Option: Function:
See par. 21-14,
Ext. 1 Feedback Source , for details.
21-35 Ext. 2 Setpoint
Option: Function:
See par. 21-15,
Ext. 1 Setpoint , for details.
21-37 Ext. 2 Reference [Unit]
Option: Function:
See par. 21-17,
Ext. 1 Reference [Unit] , for details.
21-38 Ext. 2 Feedback [Unit]
Option: Function:
See par. 21-18,
Ext. 1 Feedback [Unit] , for details.
21-39 Ext. 2 Output [%]
Option: Function:
See par. 21-19,
Ext. 1 Output [%] , for details.
2.18.6. 21-4* Closed Loop 2 PID
Configure the Closed Loop 2 PID Controller.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
192 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
