NB!
The counters starts counting whenever the frequency converter is powered-up.
Power cycle shortly after a reset will zero the counters. EEProm data are updated
once per hour.
23-60 Trend Variable
Option: Function:
[0]
*
Power [kW or HP]
[1] Current [A]
[2] Frequency [Hz]
[3] Motor Speed [RPM] Select the desired operating variable to be monitored for Trend-
ing.
Power
[0]: Power yielded to the motor. Reference for the rela-
tive value is the rated motor power programmed in par. 1-20,
Motor Power [kW
] or par. 1-21,
Motor Power [HP]
. Actual value
can be read in par. 16-10,
Power [kW]
or par. 16-11,
Power
[Hp]
.
Current
[1]: Output current to the motor. Reference for the rel-
ative value is the rated motor current programmed in par. 1-24,
Motor Current
. Actual value can be read in par. 16-14,
Motor
Current
.
Output Frequency
[2]: Output frequency to the motor. Refer-
ence for the relative value is the maximum output frequency
programmed in par. 4-14, Motor Speed High Limit [Hz] Actual
value can be read in par. 16-13, Frequency.
Motor Speed
[4]: Speed of the motor. Reference for relative
value is the maximum motor speed programmed in par. 4-13,
Motor Speed High Limit.
23-61 Continuous Bin Data
Range: Function:
0
*
[0 - 4.294.967.295] Array with 10 elements ([0]-[9] below parameter number in
display). Press OK and step between elements by means of ▲
and ▼ buttons on the LCP.
10 counters with the frequency of occurrence for the operating
variable monitored, sorted according to the following intervals:
Counter [0]: 0% - <10%
Counter [1]: 10% - <20%
Counter [2]. 20% - <30%
Counter [3]: 30% - <40%
Counter [4]: 40% - <50%
Counter [5]: 50% - <60%
Counter [6]. 60% - <70%
Counter [7]: 70% - <80%
Counter [8]. 80% - <90%
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
223
2
