Danfoss vlt aqua Programming Guide

Counter [9]: 90% - <100% or Max
The above minimum limits for the intervals are the default limits.
These can be changed in par. 23-65,
Minimum Bin Value .
Starts to count when the frequency converter is powered up for
the first time. All counters can be reset to 0 in par. 23-66,
Reset
Continuous Bin Data
.
23-62 Timed Bin Data
Range: Function:
0
*
[0-4294967295] Array with 10 elements ([0]-[9] below parameter number in
display). Press OK and step between elements by means of ▲
and ▼ buttons on the LCP.
10 counters with the frequency of occurrence for the operating
data monitored sorted according to the intervals as for par.
23-61,
Continuous Bin Data .
Starts to count at the date/time programmed in par. 23-63,
Timed Period Start , and stops at the time/date programmed in
par. 23-64,
Timed Period Stop . All counters can be reset to 0 in
par. 23-67,
Reset Timed Bin Data .
23-63 Timed Period Start
Range: Function:
2000-01
-01
00:00
*
[2000-01-01 00:00 -
2099-12-31 23:59]
Set the date and time at which the Trending starts the update
of the Timed Bin counters.
Date format will depend on setting in par. 0-71,
Date Format ,
and time format on setting in par. 0-72,
Time Format .
NB!
The frequency converter has no back up of the
clock function and the set date/time will reset to
default (2000-01-01 00:00) after a power down
unless a Real Time Clock module with back up is
installed. Consequently the logging will be stop-
ped until date/time is readjusted in par. 0-70,
Set
Date and Time
. In par. 0-79, Clock Fault , it is pos-
sible to program for a Warning in case clock not
has been set properly, e.g. after a power down.
23-64 Timed Period Stop
Range: Function:
2000-01
-01
00:00
*
[2000-01-01 00:00 -
2099-12-31 23:59]
Set the date and time at which the Trend Analyses must stop
update of the Timed Bin counters.
Date format will depend on setting in par. 0-71,
Date Format ,
and time format on setting in par. 0-72,
Time Format .
2. Parameter Description VLT
®
AQUA Drive Programming Guide
224 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
