Danfoss vlt aqua Programming Guide

[5] Ni 1000 (°F) Terminal X42/3 can be programmed as an analog input accept-
ing a voltage or input from either Pt 1000 or Ni 1000 tempera-
ture sensors. Select the desired mode.
Pt 1000, [2] and Ni 1000, [4] if operating in Celsius - Pt 1000,
[3] and Ni 1000, [5] if operating in Fahrenheit.
Notice: If the input is not in use, it must be set for Voltage!
If set for temperature and used as feed back, the unit must be
set for either Celsius or Fahrenheit (par.20-12, 21-10, 21-30 or
21-50)
26-02 Terminal X42/5 Mode
Option: Function:
[1] Voltage
[2] Pt 1000 (°C)
[3] Pt 1000 (°F)
[4] Ni 1000 (°C)
[5] Ni 1000 (°F) Terminal X42/5 can be programmed as an analog input accept-
ing a voltage or input from either Pt 1000 or Ni 1000 tempera-
ture sensors. Select the desired mode.
Pt 1000, [2] and Ni 1000, [4] if operating in Celsius - Pt 1000,
[3] and Ni 1000, [5] if operating in Fahrenheit.
Notice: If the input is not in use, it must be set for Voltage!
If set for temperature and used as feed back, the unit must be
set for either Celsius or Fahrenheit (par.20-12, 21-10, 21-30 or
21-50)
26-10 Terminal X42/1 Low Voltage
Range: Function:
0.07 V
*
[0.00 - par. 26-11] Enter the low voltage value. This analog input scaling value
should correspond to the low reference/feedback value set in
par 26-14.
26-11 Terminal X42/1 High Voltage
Range: Function:
10.0 V
*
[Par. 26-10 - 10.0 V] Enter the high voltage value. This analog input scaling value
should correspond to the high reference/feedback value set in
par. 26-15.
26-14 Terminal X42/1 Low Ref./feedb. Value
Range: Function:
0.000
Unit
*
[-100000.000 - par.
26-15]
Enter the analog input scaling value that corresponds to the low
voltage value set in par 26-10.
2. Parameter Description VLT
®
AQUA Drive Programming Guide
246 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2
