[72] Logic Rule 2 See par. group 13-4*. If Logic Rule 2 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[73] Logic Rule 3 See par. group 13-4*. If Logic Rule 3 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[74] Logic Rule 4 See par. group 13-4*. If Logic Rule 4 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[75] Logic Rule 5 See par. group 13-4*. If Logic Rule 5 is evaluated as TRUE, the
output will go high. Otherwise, it will be low.
[80] SL Digital Output A See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [38]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [32] Set
dig. out. A low is executed.
[81] SL Digital Output B See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [39]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [33]
Set
dig. out. A low
is executed.
[82] SL Digital Output C See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [40]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [34]
Set
dig. out. A low
is executed.
[83] SL Digital Output D See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [41]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [35]
Set
dig. out. A low
is executed.
[84] SL Digital Output E See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [42]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [36]
Set
dig. out. A low
is executed.
[85] SL Digital Output F See par. 13-52
SL Control Action . The input will go high when-
ever the Smart Logic Action [43]
Set dig. out. A high is executed.
The input will go low whenever the Smart Logic Action [37]
Set
dig. out. A low
is executed.
[160] No alarm Output is high when no alarm is present.
[161] Running reverse The output is high when the frequency converter is running
counter clockwise (the logical product of the status bits ‘running’
AND ‘reverse’).
[165] Local reference active Output is high when par. 3-13
Reference Site = [2] Local or
when par. 3-13
Reference Site = [0] Linked to hand auto at the
same time as the LCP is in Hand on mode.
[166] Remote reference ac-
tive
Output is high when par. 3-13
Reference Site = Remote [1] or
Linked to hand/auto [0] while the LCP is in [Auto on] mode.
[167] Start command active Output is high when there is an active Start command (i.e. via
digital input bus connection or [Hand on] or [Auto on], and no
Stop or Start command is active.
[168] Drive in hand mode Output is high when the frequency converter is in Hand on mode
(as indicated by the LED light above [Hand on].
2. Parameter Description VLT
®
AQUA Drive Programming Guide
86 MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
2

Danfoss vlt aqua Specifications

General

Supply Voltage	200-240V, 380-500V, 525-600V
Enclosure	IP20
Features	Energy optimization
Approvals	CE, UL, cUL
Input Voltage Range	200-240V, 380-500V, 525-600V
Output Voltage Range	0 to supply voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Short circuit, Ground fault
Communication Interfaces	PROFIBUS
Cooling Method	Air-cooled
