Page #95 background imageLoading...
Page #95 background image
5-68 Pulse Output Maximum Frequency #X30/6
Range: Function:
5000Hz
*
[0 - 32000 Hz] Select the maximum frequency on terminal X30/6 referring to
the output variable in par. 5-66. This parameter cannot be ad-
justed while the motor is running.
This parameter is active when option module MCB 101 is moun-
ted in the frequency converter.
2.7.8. 5-9* Bus Controlled
This parameter group selects digital and relay outputs via a fieldbus setting.
5-90 Digital & Relay Bus Control
Range: Function:
[0 - FFFFFFFF] This parameter holds the state of the digital outputs and relays
that is controlled by bus.
A logical '1' indicates that the output is high or active.
A logical '0' indicates that the output is low or inactive.
Bit 0 CC Digital Output Terminal 27
Bit 1 CC Digital Output Terminal 29
Bit 2 GPIO Digital Output Terminal X 30/6
Bit 3 GPIO Digital Output Terminal X 30/7
Bit 4 CC Relay 1 output terminal
Bit 5 CC Relay 2 output terminal
Bit 6 Option B Relay 1 output terminal
Bit 7 Option B Relay 2 output terminal
Bit 8 Option B Relay 3 output terminal
Bit 9-15 Reserved for future terminals
Bit 16 Option C Relay 1 output terminal
Bit 17 Option C Relay 2 output terminal
Bit 18 Option C Relay 3 output terminal
Bit 19 Option C Relay 4 output terminal
Bit 20 Option C Relay 5 output terminal
Bit 21 Option C Relay 6 output terminal
Bit 22 Option C Relay 7 output terminal
Bit 23 Option C Relay 8 output terminal
Bit 24-31 Reserved for future terminals
5-93 Pulse Out #27 Bus Control
Range: Function:
160 %
*
[1 - 1000 %] Contains the frequency to apply to the digital output terminal
27, when it is configured as [Bus Controlled].
5-94 Pulse Out #27 Timeout Preset
Range: Function:
0 %
*
[0 - 100 %] Contains the frequency to apply to the digital output terminal
27, when it is configured as [Bus Controlled Timeout] and time-
out is detected.
VLT
®
AQUA Drive Programming Guide 2. Parameter Description
MG.20.O2.02 - VLT
®
is a registered Danfoss trademark
95
2
