Danfoss VLT AutomationDrive FC 300 Series Programming Guide

-
Parameter 4-95 Positive Torque Limit
Table 321: Parameter 4-95 Positive Torque Limit
4-95 Positive Torque Limit
Default value: Size related
Parameter type: Range, 1 - 160.0%
Setup: All setups
Conversion index: -1
Data type: Uint16
Change during operation: True
Enter the limit for the motor torque when the rotation direction is clockwise.
Parameter 4-96 Negative Torque Limit
Table 322: Parameter 4-96 Negative Torque Limit
4-96 Negative Torque Limit
Default value: Size related
Parameter type: Range, 1 - 160.0%
Setup: All setups
Conversion index: -1
Data type: Uint16
Change during operation: True
Enter the limit for the motor torque when the rotation direction is counterclockwise.
5.6 Parameter Group 5-** Digital In/Out
5.6.1 5-0* Digital I/O Mode
N O T I C E
The following parameter is only available in FC 302:
Parameter 5-02 Terminal 29 Mode
Parameters for configuring the input and output using NPN and PNP.
Parameter 5-00 Digital I/O Mode
Table 323: Parameter 5-00 Digital I/O Mode
5-00 Digital I/O Mode
Default value: [0] PNP
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: False
N O T I C E
Perform a power cycle to activate the parameter once it has been changed.
Digital inputs and programmed digital outputs are preprogrammable for operation either in PNP or NPN systems.
Option
Name
Description
[0]*
PNP
Action on positive directional pulses (↕). PNP systems are pulled down to GND.
[1]
NPN
Action on negative directional pulses (↕). NPN systems are pulled up to +24 V, internally in the drive.
Parameter 5-01 Terminal 27 Mode
Table 324: Parameter 5-01 Terminal 27 Mode
5-01 Terminal 27 Mode
Default value: [0] Input
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334 | 175Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
