Danfoss VLT AutomationDrive FC 300 Series Programming Guide

Option
Name
Description
[4594]
Sensor 2 [%]
[4595]
Sensor 2 [unit]
[4596]
Sensor 3 [%]
[4597]
Sensor 3 [unit]
[4598]
Sensor 4 [%]
[4599]
Sensor 4 [unit]
5.12 Parameter Group 12-** Ethernet
5.12.1 12-0* IP Settings
Parameter 12-01 IP Address
Table 604: Parameter 12-01 IP Address
12-01 IP Address
Default value: 0
Parameter type: Range, 0 - 4294967295
Setup: 1 setup
Conversion index: 0
Data type: OctetString
Change during operation: True
Configure the IP address of the option. Read-only if parameter 12-00 IP Address Assignment is set to [1] DHCP, [2] BOOTP, or via DIP
switches. In POWERLINK, the IP address follows the last byte of parameter 12-60 Node ID and the 1
st
part is fixed to 192.168.100
(node ID).
Parameter 12-02 Subnet Mask
Table 605: Parameter 12-02 Subnet Mask
12-02 Subnet Mask
Default value: 0
Parameter type: Range, 0 - 4294967295
Setup: 1 setup
Conversion index: 0
Data type: OctetString
Change during operation: True
Configure the IP subnet mask of the option. Read-only if parameter 12-00 IP Address Assignment is set to [1] DHCP or [2] BOOTP. In
POWERLINK, it is fixed to 255.255.255.0
Parameter 12-03 Default Gateway
Table 606: Parameter 12-03 Default Gateway
12-03 Default Gateway
Default value: 0
Parameter type: Range, 0 - 4294967295
Setup: 1 setup
Conversion index: 0
Data type: OctetString
Change during operation: True
Configure the IP default gateway of the option. Read-only if parameter 12-00 IP Address Assignment set to [1] DHCP or [2] BOOTP. In a
non-routed network, this address is set to the IP address of the I/O device.
Parameter 12-04 DHCP Server
Table 607: Parameter 12-04 DHCP Server
12-04 DHCP Server
Default value: 0
Parameter type: Range, 0 - 2147483647
Setup: 2 setups
Conversion index: 0
Data type: OctetString
Change during operation: True
AU275636650261en-000101 / 130R0334348 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
