5.25.1 32-0* Encoder 2
Parameter 32-00 Incremental Signal Type
Table 1111: Parameter 32-00 Incremental Signal Type
32-00 Incremental Signal Type
Default value: [1] RS422 (5V TTL)
Parameter type: Option
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]
None
[1]*
RS422 (5V TTL)
[2]
Sinusoidal 1Vpp
[3]
CAN encoder
Parameter 32-01 Incremental Resolution
Table 1112: Parameter 32-01 Incremental Resolution
32-01 Incremental Resolution
Default value: 1024
Parameter type: Range, 1 - 1073741823
Setup: All setups
Conversion index: 0
Data type: Uint32
Change during operation: True
Set the resolution of the incremental encoder connected to terminal X55. The maximum frequency must not exceed 410 kHz.
Parameter 32-02 Absolute Protocol
Table 1113: Parameter 32-02 Absolute Protocol
32-02 Absolute Protocol
Default Value: [0] None
Parameter Type: Option
Setup: 2 setups
Conversion Index: -
Data Type: Uint8
Change during operation: True
Option
Name
Description
[0]*
None
[1]
HIPERFACE
[2]
EnDat
[4]
SSI
[5]
SSI with filter
[6]
BiSS-C
[7]
BiSS-B
