Main menu provides access to all parameters.
Quick menu takes the user through a few parameters, making it possible to start operating the drive. Change a parameter in either
main menu mode or quick menu mode.
4.1.5 Quick Menu Key Functions
Press [Quick Menu] to enter a list of different areas contained in the Quick Menu.
e30bc916.10
Q1 My Personal Menu
Q2 Quick Setup
Q4 Smart Setup
Q5 Changes Made
0RPM 0.00A 1(1)
Quick Menus
Illustration 13: Quick Menus
Select Q1 My Personal Menu to show the selected personal parameters. These parameters are selected in parameter 0-25 My Personal
Menu. Up to 50 different parameters can be added in this menu.
Select Q2 Quick Setup to go through a selection of parameters to get the motor running almost optimally. The default settings for
the other parameters consider the required control functions and the configuration of signal inputs/outputs (control terminals).
The parameter selection is effected with the navigation keys. The parameters in the following table are accessible.
Table 2: Selection of Parameter
Parameter
Setting
Parameter 0-01 Language
Select the language. Default is [0] English.
Parameter 1-20 Motor Power [kW]
[kW]
Parameter 1-22 Motor Voltage
[V]
Parameter 1-23 Motor Frequency
[Hz]
Parameter 1-24 Motor Current
[A]
Parameter 1-25 Motor Nominal Speed
[RPM]
Parameter 5-12 Terminal 27 Digital Input
[0] No function
(1)
Parameter 1-29 Automatic Motor Adaptation (AMA)
[1] Enable complete AMA
Parameter 3-02 Minimum Reference
[RPM]
Parameter 3-03 Maximum Reference
[RPM]
Parameter 3-41 Ramp 1 Ramp Up Time
[s]
Parameter 3-42 Ramp 1 Ramp Down Time
[s]
Parameter 3-13 Reference Site
Select whether to control the drive via digital inputs, LCP, or remote control.
1
If terminal 27 is set to [0] No operation, no connection to +24 V on terminal 27 is necessary.
Select Changes made to get information about:
The last 10 changes. Use the [▵] [▿] navigation keys to scroll between the last 10 changed parameters.
The changes made since default setting.
Select Loggings to get information about the shown line readouts. The information is shown as graphs. Only parameters selected in
parameter 0-20 Display Line 1.1 Small and parameter 0-24 Display Line 3 Large can be viewed. It is possible to store up to 120 samples
in the memory for later reference.
AU275636650261en-000101 / 130R0334 | 25Danfoss A/S © 2022.12
How to Program
VLT AutomationDrive FC 301/302
Programming Guide
