Option
Name
Description
[0]*
Off
No change of the acoustic motor switching noise.
[1]
On
Select to reduce the acoustic noise from the motor.
Parameter 14-05 PWM Generation
Table 706: Parameter 14-05 PWM Generation
14-05 PWM Generation
Default value: [0] Standard
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: True
Use this parameter in VVC+ and U/f mode only. When running with low ratio between switch frequency and output frequency (es-
pecially close to or <10:1), it is possible to improve the resolution of the PWM modulation and optimize the output voltage.
Option
Name
Description
[0]*
Standard
Use this setting for standard motors.
[1]
Double update
Updates the PWM pattern twice per switch period. Select this option to achieve a more optimal sinus-
wave and slight increase of the output voltage.
Parameter 14-06 Dead Time Compensation
Table 707: Parameter 14-06 Dead Time Compensation
14-06 Dead Time Compensation
Default value: [1] On
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: True
Option
Name
Description
[0]
Off
No compensation.
[1]*
On
Activates dead-time compensation.
5.14.2 14-1* Mains On/Off
N O T I C E
The following parameter is only available in FC 302:
Parameter 14-16 Kin. Back-up Gain
Parameters for configuring mains failure monitoring and handling. If a mains failure appears, the drive tries to continue in a control-
led way until the power in the DC link is exhausted.
Parameter 14-10 Mains Failure
Table 708: Parameter 14-10 Mains Failure
14-10 Mains Failure
Default value: [0] No function
Parameter type: Option
Setup: All setups
Conversion index: -
Data type: Uint8
Change during operation: True
When parameter 1-00 Configuration Mode is set to [2] Torque, the following options are inactive:
AU275636650261en-000101 / 130R0334 | 453Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
