Table 374: Options for Readout Output Variables
Option
Name
Description
Parameters for configuring the scaling and output functions of pulse outputs. The pulse out-
puts are designated to terminals 27 or 29. Select terminal 27 output in parameter 5-01 Termi-
nal 27 Mode and terminal 29 output in parameter 5-02 Terminal 29 Mode.
[0]
No operation
[45]
Bus control
[48]
Bus control timeout
[51]
MCO-controlled
[97]
Reference after ramp
N O T I C E
This option is available only with software version 48.XX.
Actual speed reference after the ramp. Use this output as master signal for speed synchroni-
zation of follower drives. The reference is set in parameter 16-48 Speed Ref. After Ramp [RPM].
[99]
Virtual master speed
N O T I C E
This option is only available with software version 48.XX.
Virtual master signal for controlling the speed or position the followers.
[100]
Output frequency
[101]
Reference
[102]
Feedback
[103]
Motor current
[104]
Torque relative to limit
[105]
Torque relative to rated
[106]
Power
[107]
Speed
[108]
Torque
[109]
Max. out freq
Parameter 5-60 Terminal 27 Pulse Output Variable
Table 375: Parameter 5-60 Terminal 27 Pulse Output Variable
5-60 Terminal 27 Pulse Output Variable
Default value: Size related
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
AU275636650261en-000101 / 130R0334 | 221Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
