Danfoss VLT AutomationDrive FC 300 Series Programming Guide

Parameter 6-60 Terminal X30/8 Output
Table 431: Parameter 6-60 Terminal X30/8 Output
6-60 Terminal X30/8 Output
Default value: [0] No operation
Parameter type: Option
Setup: All setups
Conversion index: –
Data type: Uint8
Change during operation: True
Select the function of terminal X30/8 as an analog current output. Depending on the selection, the output is either a 0–20 mA or 4–
20 mA output. The current value can be read out in the LCP in parameter 16-65 Analog Output 42 [mA].
Option
Name
Description
[0]*
No operation
Indicates no signal on the analog output.
[52]
MCO
[53]
MCO 4–20mA
[58]
Actual position
N O T I C E
This option is available only with software version 48.XX.
The actual position. 0–20 mA corresponds to parameter 3-06 Minimum Position to parameter 3-07
Maximum Position.
[59]
Actual position
4–20 mA
N O T I C E
This option is available only with software version 48.XX.
The actual position. 4–20 mA corresponds to parameter 3-06 Minimum Position to parameter 3-07
Maximum Position.
[100]
Output frequency
0 Hz = 0 mA; 100 Hz = 20 mA.
[101]
Reference
Parameter 3-00 Reference Range [Min - Max] 0% = 0 mA; 100% = 20 mA
Parameter 3-00 Reference Range [-Max - Max] -100% = 0 mA; 0% = 10 mA; +100% = 20 mA.
[102]
Feedback
[103]
Motor current
The value is taken from parameter 16-37 Inv. Max. Current. The inverter maximum current (160%
current) is equal to 20 mA.
Example: Inverter normal current (11 kW) is 24 A. 160 %=38.4 A. Motor normal current is 22 A, the
readout is 11.46 mA.
20mA × 22A
38 . 4A
 = 11 . 46mA
When the normal motor current is equal to 20 mA, the output setting of parameter 6-52 Terminal
42 Output Max Scale is:
IVLT, MAX × 100
IMotor, Nom
 = 
38 . 4 × 100
22
 = 175 %
[104]
Torque rel to limit
The torque setting is related to the setting in parameter 4-16 Torque Limit Motor Mode.
[105]
Torque relate to
rated
The torque is related to the motor torque setting.
[106]
Power
Taken from parameter 1-20 Motor Power [kW].
AU275636650261en-000101 / 130R0334 | 243Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
