Danfoss VLT AutomationDrive FC 300 Series Programming Guide

Option
Name
Description
Positioning is completed and the on-target signal is sent when the actual position is within
parameter 3-05 On Reference Window for the duration of parameter 3-09 On Target Time and
the actual speed does not exceed parameter 3-05 On Reference Window.
[224]
Position error
N O T I C E
This option is only available with software version 48.2X and newer.
The position error exceeds the value in parameter 4-71 Maximum Position Error for the time
set in parameter 4-72 Position Error Timeout.
[225]
Position limit
N O T I C E
This option is only available with software version 48.2X and newer.
The position is outside the limits set in parameter 3-06 Minimum Position and parameter 3-07
Maximum Position.
[226]
Touch on target
N O T I C E
This option is only available with software version 48.2X and newer.
Target position is reached in touch probe position mode.
[227]
Touch activated
Touch probe positioning active. The drive monitors the touch probe sensor input.
[228]
Comparator 6
[229]
Comparator 7
[230]
Comparator 8
[231]
Comparator 9
[232]
Logic rule 6
[233]
Logic rule 7
[234]
Logic rule 8
[235]
Logic rule 9
[236]
SL time-out 8
[237]
SL time-out 9
[238]
RS flipflop 8
[239]
RS flipflop 9
[240]
SL digital output A
[241]
SL digital output B
[242]
SL digital output C
AU275636650261en-000101 / 130R0334 | 393Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
