ID
Name
Setup 1
1392.2
Alert Text
User Alert
1392.3
Alert Text
User Alert
1392.4
Alert Text
User Alert
1392.5
Alert Text
User Alert
1392.6
Alert Text
User Alert
1392.7
Alert Text
User Alert
1392.8
Alert Text
Dig In 33
1392.9
Alert Text
User Alert
Example 1: In parameter 13-90 Alert Trigger, index [0], DI19 is selected as trigger. The digital value is 0000 0001. The corresponding
action, Info, is set in parameter 13-91 Alert Action, index [0] and is shown as 1 hex in parameter 13-99 Alert Status Word.
Example 2: In parameter 13-90 Alert Trigger, index [1], DI32 is selected as trigger. The digital value is 0000 0010. The corresponding
action, Warning, is set in parameter 13-91 Alert Action, index [1] and is shown as 2 hex in parameter 13-98 Alert Warning Word.
Example 3: In parameter 13-90 Alert Trigger, index [8], DI33 is selected as trigger. The digital value is 0001 0000 0000. The corre-
sponding action, Trip, is set in parameter 13-91 Alert Action, index [8] and is shown as 100 hex in parameter 13-97 Alert Alarm Word.
When 1 of the 3 digital inputs shown in this example is activated, the text shown in the LCP is the one defined in parameter 13-92
Alert Text, index [0], [1], and [8].
N O T I C E
The action setting of an active trigger cannot be changed. For example, if DI19 is selected as trigger and the input is high, the
action cannot be changed from Stop to Jog.
Parameter 13-90 Alert Trigger
Table 695: Parameter 13-90 Alert Trigger
13-90 Alert Trigger
Default value: [0] False
Parameter type: Option, Array [10]
Setup: 2 setups
Conversion index: -
Data type: Uint8
Change during operation: True
Select the event that triggers the user-defined action and message.
Option
Name
Description
[0]*
False
[1]
True
[18]
Reversing
[22]
Comparator 0
[23]
Comparator 1
[24]
Comparator 2
[25]
Comparator 3
[26]
Logic rule 0
[27]
Logic rule 1
AU275636650261en-000101 / 130R0334 | 447Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
