Option
Name
Description
[0]
None
[1]
Safe option
Parameter 42-11 Encoder Resolution
Table 1373: Parameter 42-11 Encoder Resolution
42-11 Encoder Resolution
Default value: [1024]
Parameter type: Range, 1 - config. dependent
Setup: 1 setup
Conversion index: 0
Data type: Uint16
Change during operation: False
Encoder or proximity switch resolution of the encoder connected to the MCB 150 TTL and MCB 151 HTL.
Parameter 42-12 Encoder Direction
Table 1374: Parameter 42-12 Encoder Direction
42-12 Encoder Direction
Default value: [0] Clockwise
Parameter type: Option
Setup: 1 setup
Conversion index: -
Data type: Uint8
Change during operation: False
Option
Name
Description
[0]*
Clockwise
[1]
Counterclockwise
Parameter 42-13 Gear Ratio
Table 1375: Parameter 42-13 Gear Ratio
42-13 Gear Ratio
Default value: 1
Parameter type: Range, 0.0001 - 1000.0000
Setup: 1 setup
Conversion index: 0
Data type: Uint32
Change during operation: False
Ratio between motor speed and encoder speed.
N O T I C E
Only use when the drive is gear-mounted.
Parameter 42-14 Feedback Type
Table 1376: Parameter 42-14 Feedback Type
42-14 Feedback Type
Default value: [0] With direction info
Parameter type: Option
Setup: 1 setup
Conversion index: -
Data type: Uint8
Change during operation: False
Option
Name
Description
[0]*
With direction info
[1]
Without direction info
AU275636650261en-000101 / 130R0334 | 669Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
