Danfoss VLT AutomationDrive FC 300 Series Programming Guide

-
-
-
-
-
-
-
-
-
-
-
-
-
-
N O T I C E
Setting this parameter sets the following parameters to their default settings:
Parameter 1-15 Low Speed Filter Time Const.
Parameter 1-16 High Speed Filter Time Const.
Parameter 1-17 Voltage Filter Time Const.
Parameter 1-30 Stator Resistance (Rs)
Parameter 1-31 Rotor Resistance (Rr)
Parameter 1-33 Stator Leakage Reactance (X1)
Parameter 1-34 Rotor Leakage Reactance (X2)
Parameter 1-35 Main Reactance (Xh)
Parameter 1-36 Iron Loss Resistance (Rfe)
Parameter 4-18 Current Limit
Parameter 14-31 Current Lim Ctrl, Integration Time
Parameter 14-43 Motor Cosphi
Parameter 45-33 Alarm High
Parameter 45-62 Load Threshold
Enter the nominal motor current value from the motor nameplate data. The data is used for calculating torque, motor overload
protection, and so on.
Parameter 1-25 Motor Nominal Speed
Table 81: Parameter 1-25 Motor Nominal Speed
1-25 Motor Nominal Speed
Default value: Size related
Parameter type: Range, 10 - 60000 RPM
Setup: All setups
Conversion index: 67
Data type: Uint16
Change during operation: False
N O T I C E
This parameter cannot be adjusted while the motor is running.
N O T I C E
Changing this parameter will affect settings of other parameters.
Enter the nominal motor speed value from the motor nameplate data. The data is used for calculating motor compensations.
nm, n = ns − nslip
Parameter 1-26 Motor Cont. Rated Torque
Table 82: Parameter 1-26 Motor Cont. Rated Torque
1-26 Motor Cont. Rated Torque
Default value: Size related
Parameter type: Range, 0.1 - 10000.0 Nm
Setup: All setups
Conversion index: -1
Data type: Uint32
Change during operation: False
N O T I C E
Changing this parameter sets certain other parameters to their default settings.
AU275636650261en-000101 / 130R033478 | Danfoss A/S © 2022.12
Parameter Descriptions
VLT AutomationDrive FC 301/302
Programming Guide
