13-20 SL Controller Timer
Range: Function:
Application
dependent*
[Application dependant] Enter the value to define the duration of the FALSE output from the programmed timer. A timer is
only FALSE if it is started by an action (i.e.
Start timer 1 [29]
) and until the given timer value has
elapsed.
3.14.5 13-4* Logic Rules
Combine up to three boolean inputs (TRUE / FALSE inputs) from timers, comparators, digital inputs, status bits and events using the logical operators
AND, OR, and NOT. Select boolean inputs for the calculation in par. 13-40
Logic Rule Boolean 1
, par. 13-42
Logic Rule Boolean 2
and par. 13-44
Logic
Rule Boolean 3
. Define the operators used to logically combine the selected inputs in par. 13-41
Logic Rule Operator 1
and par. 13-43
Logic Rule Operator
2
.
Priority of calculation
The results of par. 13-40
Logic Rule Boolean 1
, par. 13-41
Logic Rule Operator 1
and par. 13-42
Logic Rule Boolean 2
are calculated first. The outcome
(TRUE / FALSE) of this calculation is combined with the settings of par. 13-43
Logic Rule Operator 2
and par. 13-44
Logic Rule Boolean 3
, yielding the
final result (TRUE / FALSE) of the logic rule.
13-40 Logic Rule Boolean 1
Array [6]
Option: Function:
[0] * False Select the first boolean (TRUE or FALSE) input for the selected logic rule.
See par. 13-01
Start Event
([0] - [61]) and par. 13-02
Stop Event
([70] - [75]) for further description.
[1] True
[2] Running
[3] In range
[4] On reference
[5] Torque limit
[6] Current limit
[7] Out of current range
[8] Below I low
[9] Above I high
[10] Out of speed range
[11] Below speed low
[12] Above speed high
[13] Out of feedb. range
[14] Below feedb. low
[15] Above feedb. high
[16] Thermal warning
[17] Mains out of range
[18] Reversing
[19] Warning
[20] Alarm (trip)
[21] Alarm (trip lock)
[22] Comparator 0
[23] Comparator 1
[24] Comparator 2
[25] Comparator 3
[26] Logic rule 0
3 Parameter descriptions FC 300 Programming Guide
184
MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
