Danfoss VLT AutomationDrive FC 300 Programming Guide

This parameter cannot be adjusted while the motor is running. This parameter is visible in LCP if
par. 0-03
Regional Settings is International [0].
NB!
Four sizes down, one size up from nominal unit rating.
1-21 Motor Power [HP]
Range: Function:
Application
dependent*
[Application dependant] Enter the nominal motor power in HP according to the motor nameplate data. The default value
corresponds to the nominal rated output of the unit. This parameter is visible in LCP if
par. 0-03
Regional Settings is US [1]
1-22 Motor Voltage
Range: Function:
Application
dependent*
[Application dependant] Enter the nominal motor voltage according to the motor nameplate data. The default value corre-
sponds to the nominal rated output of the unit.
1-23 Motor Frequency
Range: Function:
Application
dependent*
[20 - 1000 Hz] Min - Max motor frequency: 20 - 1000 Hz.
Select the motor frequency value from the motor nameplate data. If a value different from 50 Hz
or 60 Hz is selected, it is necessary to adapt the load independent settings in par. 1-50
Motor
Magnetisation at Zero Speed
to par. 1-53 Model Shift Frequency . For 87 Hz operation with 230/400
V motors, set the nameplate data for 230 V/50 Hz. Adapt par. 4-13
Motor Speed High Limit
[RPM]
and par. 3-03 Maximum Reference to the 87 Hz application.
1-24 Motor Current
Range: Function:
Application
dependent*
[Application dependant] Enter the nominal motor current value from the motor nameplate data. The data are used for cal-
culating torque, motor protection etc.
1-25 Motor Nominal Speed
Range: Function:
Application
dependent*
[10 - 60000 RPM] Enter the nominal motor speed value from the motor nameplate data. The data are used for cal-
culating motor compensations.
NB!
Motor speed must always be lower than synchronous speed.
1-26 Motor Cont. Rated Torque
Range: Function:
Application
dependent*
[0.1 - 10000.0 Nm] Enter the value from the motor nameplate data. The default value corresponds to the nominal rated
output. This parameter is available when par. 1-10
Motor Construction is set to PM, non salient
SPM
[1], i.e. the parameter is valid for PM and non-salient SPM motors only.
1-29 Automatic Motor Adaptation (AMA)
Option: Function:
The AMA function optimises dynamic motor performance by automatically optimising the advanced
motor parameters (par. 1-30
Stator Resistance (Rs) to par. 1-35 Main Reactance (Xh) ) at motor
standstill.
3 Parameter descriptions FC 300 Programming Guide
48 MG.33.M8.02 - VLT
®
is a registered Danfoss trademark
3
