8-42 PCD Write Conguration
Range: Function:
[2643] Terminal
X42/7 Bus
Control
[2653] Terminal
X42/9 Bus
Control
[2663] Terminal
X42/11 Bus
Control
[3401] PCD 1 Write
to MCO
[3402] PCD 2 Write
to MCO
[3403] PCD 3 Write
to MCO
[3404] PCD 4 Write
to MCO
[3405] PCD 5 Write
to MCO
[3406] PCD 6 Write
to MCO
[3407] PCD 7 Write
to MCO
[3408] PCD 8 Write
to MCO
[3409] PCD 9 Write
to MCO
[3410] PCD 10 Write
to MCO
[3644] Terminal
X49/7 Bus
Control
[3654] Terminal
X49/9 Bus
Control
[3664] Terminal
X49/11 Bus
Control
8-43 PCD Read Conguration
Range: Function:
[0] None
[15] Readout:
actual setup
[894] Bus Feedback
1
[895] Bus Feedback
2
[896] Bus Feedback
3
[1397] Alert Alarm
Word
[1398] Alert Warning
Word
8-43 PCD Read Conguration
Range: Function:
[1399] Alert Status
Word
[1500] Operating
hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference
[Unit]
[1602] Reference [%]
[1603] Status Word
[1605] Main Actual
Value [%]
[1609] Custom
Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1619] Thermistor
Sensor
Temperature
[1622] Torque [%]
[1623] Motor Shaft
Power [kW]
[1624] Calibrated
Stator
Resistance
[1626] Power Filtered
[kW]
[1627] Power Filtered
[hp]
[1630] DC Link
Voltage
[1632] Brake
Energy /s
[1633] Brake Energy
Average
[1634] Heatsink
Temp.
[1635] Inverter
Thermal
[1638] SL Controller
State
[1639] Control Card
Temp.
[1642] Service Log
Counter
Parameter Descriptions VLT® AutomationDrive FC 361
100 Danfoss A/S © 03/2019 All rights reserved. MG06J202
44
