Danfoss VLT AutomationDrive FC 361 Programming Guide

17-61 Feedback Signal Monitoring
Select which action the frequency converter should take if a
faulty encoder signal is detected.
The encoder function in parameter 17-61 Feedback Signal
Monitoring is an electrical check of the hardware circuit in the
encoder system.
Option: Function:
[0] Disabled
[1] * Warning
[2] Trip
[3] Jog
[4] Freeze Output
[5] Max Speed
[6] Switch to
Open Loop
[7] Select Setup 1
[8] Select Setup 2
[9] Select Setup 3
[10] Select Setup 4
[11] Stop & Trip
[12] Trip/Warning
[13] Trip/Catch
4.17 Parameters: 18-** Data Readouts 2
4.17.1 18-5* Active Alarms/Warnings
The parameters in this group show the numbers of
currently active alarms or warnings.
18-55 Active Alarm Numbers
Range: Function:
0* [0 - 65535] This parameter contains an array of
up to 20 alarms that are currently
active. The value 0 means no alarm.
18-56 Active Warning Numbers
Range: Function:
0* [0 - 65535] This parameter contains an array of
up to 20 warnings that are
currently active. The value 0 means
no warning.
18-90 Process PID Error
Range: Function:
0 %* [-200 -
200 %]
Give the present error value used
by the process PID controller.
18-91 Process PID Output
Range: Function:
0 %* [-200 -
200 %]
Give the present raw output value
from the process PID controller.
18-92 Process PID Clamped Output
Range: Function:
0 %* [-200 -
200 %]
Give the present output value from
the process PID controller after the
clamp limits have been observed.
18-93 Process PID Gain Scaled Output
Range: Function:
0 %* [-200 -
200 %]
Give the present output value from
the process PID controller after the
clamp limits have been observed,
and the resulting value has been
gain scaled.
4.18
Parameters: 21-** Ext. Closed Loop
21-10 Ext. 1 Ref./Feedback Unit
Select the unit to be used with closed loop 1.
Option: Function:
[0] None
[1] * %
[5] PPM
[10] 1/min
[11] rpm
[12] Pulse/s
[20] l/s
[21] l/min
[22] l/h
[23] m³/s
[24] m³/min
[25] m³/h
[30] kg/s
[31] kg/min
[32] kg/h
[33] t/min
[34] t/h
[40] m/s
[41] m/min
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 151
4 4
