Danfoss VLT AutomationDrive FC 361 Programming Guide

9-15 PCD Write Conguration
Array [10]
Option: Function:
[590] Digital & Relay
Bus Control
[593] Pulse Out #27
Bus Control
[595] Pulse Out #29
Bus Control
[597] Pulse Out
#X30/6 Bus
Control
[615] Terminal 53
High Ref./
Feedb. Value
[625] Terminal 54
High Ref./
Feedb. Value
[653] Term 42
Output Bus
Ctrl
[663] Terminal
X30/8 Bus
Control
[748] PCD Feed
Forward
[890] Bus Jog 1
Speed
[891] Bus Jog 2
Speed
[1680] Fieldbus CTW
1
[1682] Fieldbus REF 1
[1685] FC Port CTW 1
[1686] FC Port REF 1
9-16 PCD Read Conguration
Array [10]
Option: Function:
Select the parameters to be
assigned to PCD 3–10 of the
telegrams. The number of available
PCDs depends on the telegram
type. PCDs 3–10 contain the actual
data values of the selected
parameters. For standard PROFIBUS
telegram, see
parameter 9-22 Telegram Selection.
[0] None
[1500] Operating
hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
9-16 PCD Read Conguration
Array [10]
Option: Function:
[1601] Reference
[Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual
Value [%]
[1609] Custom
Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1620] Motor Angle
[1621] Torque [%]
High Res.
[1622] Torque [%]
[1624] Calibrated
Stator
Resistance
[1630] DC Link
Voltage
[1634] Heatsink
Temp.
[1635] Inverter
Thermal
[1638] SL Controller
State
[1639] Control Card
Temp.
[1645] Motor Phase U
Current
[1646] Motor Phase V
Current
[1647] Motor Phase
W Current
[1648] Speed Ref.
After Ramp
[RPM]
[1650] External
Reference
[1651] Pulse
Reference
[1652] Feedback[Unit]
[1653] Digi Pot
Reference
[1657] Feedback
[RPM]
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 105
4 4
