Danfoss VLT AutomationDrive FC 361 Programming Guide

9-23 Parameters for Signals
Array [1000]
Read only
Option: Function:
This parameter contains a list of
signals available for selection in
parameter 9-15 PCD Write Congu-
ration and parameter 9-16 PCD Read
Conguration.
[0] * None
[302] Minimum
Reference
[303] Maximum
Reference
[312] Catch up/slow
Down Value
[341] Ramp 1 Ramp
Up Time
[342] Ramp 1 Ramp
Down Time
[351] Ramp 2 Ramp
Up Time
[352] Ramp 2 Ramp
Down Time
[380] Jog Ramp
Time
[381] Quick Stop
Ramp Time
[411] Motor Speed
Low Limit
[RPM]
[412] Motor Speed
Low Limit [Hz]
[413] Motor Speed
High Limit
[RPM]
[414] Motor Speed
High Limit
[Hz]
[416] Torque Limit
Motor Mode
[417] Torque Limit
Generator
Mode
[553] Term. 29 High
Ref./Feedb.
Value
[558] Term. 33 High
Ref./Feedb.
Value
[590] Digital & Relay
Bus Control
[593] Pulse Out #27
Bus Control
9-23 Parameters for Signals
Array [1000]
Read only
Option: Function:
[595] Pulse Out #29
Bus Control
[597] Pulse Out
#X30/6 Bus
Control
[615] Terminal 53
High Ref./
Feedb. Value
[625] Terminal 54
High Ref./
Feedb. Value
[653] Term 42
Output Bus
Ctrl
[663] Terminal
X30/8 Bus
Control
[748] PCD Feed
Forward
[890] Bus Jog 1
Speed
[891] Bus Jog 2
Speed
[1500] Operating
hours
[1501] Running Hours
[1502] kWh Counter
[1600] Control Word
[1601] Reference
[Unit]
[1602] Reference %
[1603] Status Word
[1605] Main Actual
Value [%]
[1609] Custom
Readout
[1610] Power [kW]
[1611] Power [hp]
[1612] Motor Voltage
[1613] Frequency
[1614] Motor current
[1615] Frequency [%]
[1616] Torque [Nm]
[1617] Speed [RPM]
[1618] Motor Thermal
[1620] Motor Angle
[1621] Torque [%]
High Res.
[1622] Torque [%]
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 107
4 4
