Danfoss VLT AutomationDrive FC 361 Programming Guide

16-16 Torque [Nm]
Range: Function:
and thus approximately 30 ms may
pass from when an input changes
value to when the data readout
values change.
16-17 Speed [RPM]
Range: Function:
0 RPM* [-30000 -
30000 RPM]
View the actual motor RPM. In
open-loop or closed-loop process
control, the motor RPM is
estimated. In speed closed-loop
modes, the motor RPM is measured.
16-18 Motor Thermal
Range: Function:
0 %* [0 - 100 %] View the calculated thermal load on
the motor. The cutout limit is 100%.
The basis for calculation is the ETR
function selected in
parameter 1-90 Motor Thermal
Protection.
16-20 Motor Angle
Range: Function:
0* [0 - 65535] View the current encoder/resolver
angle oset relative to the index
position. The value range of 0–
65535 corresponds to 0–2xpi
(radian).
16-21 Torque [%] High Res.
Range: Function:
0 %* [-200 -
200 %]
The value shown is the torque in
percent of nominal torque, with
sign and 0.1% resolution, applied to
the motor shaft.
16-22 Torque [%]
Range: Function:
0 %* [-200 -
200 %]
Value shown is the torque in
percent of nominal torque, with
sign, applied to the motor shaft.
16-24 Calibrated Stator Resistance
Range: Function:
0.0000
Ohm*
[0.0000 -
100.0000
Ohm]
Shows the calibrated stator
resistance.
4.15.3 16-3* Drive Status
16-30 DC Link Voltage
Range: Function:
0 V* [0 - 10000 V] View a measured value. The value is
ltered with a 30 ms time constant.
16-34 Heatsink Temp.
Range: Function:
0 °C* [0 - 255 °C] View the frequency converter heat
sink temperature. The cutout limit is
90 ±5 °C (194 ±9 °F), and the
motor cuts back in at 60 ±5 °C (140
±9 °F).
16-35 Inverter Thermal
Range: Function:
0 %* [0 - 100 %] View the percentage load on the
inverter.
16-36 Inv. Nom. Current
Range: Function:
Size
related*
[0.01 - 10000
A]
View the inverter nominal current,
which must match the nameplate
data on the connected motor. The
data is used for calculation of
torque, motor overload protection,
and so on.
16-37 Inv. Max. Current
Range: Function:
Size
related*
[0.01 - 10000
A]
View the inverter maximum current,
which must match the nameplate
data on the connected motor. The
data is used for calculation of
torque, motor overload protection,
and so on.
16-38 SL Controller State
Range: Function:
0* [0 - 100] View the state of the event under
execution by the SL controller.
16-39 Control Card Temp.
Range: Function:
0 °C* [0 - 100 °C] View the temperature on the
control card, stated in °C.
Parameter Descriptions Programming Guide
MG06J202 Danfoss A/S © 03/2019 All rights reserved. 145
4 4
