21-10 Ext. 1 Ref./Feedback Unit
Option: Function:
[45] m
[60] °C
[70] mbar
[71] bar
[72] Pa
[73] kPa
[74] m WG
[80] kW
[120] GPM
[121] gal/s
[122] gal/min
[123] gal/h
[124] CFM
[125] ft³/s
[126] ft³/min
[127] ft³/h
[130] lb/s
[131] lb/min
[132] lb/h
[140] ft/s
[141] ft/min
[145] ft
[160] °F
[170] psi
[171] lb/in²
[172] in WG
[173] ft WG
[180] HP
21-11 Ext. 1 Minimum Reference
Range: Function:
0 ExtPID1Unit* [ -999999.999 -
par.
21-12 ExtPID1Unit]
Select the minimum for
the Closed Loop 1
Controller.
21-12 Ext. 1 Maximum Reference
Range: Function:
100
ExtPID1Unit*
[ par.
21-11 -
999999.999
ExtPID1Unit]
Select
the maximum for the
Closed Loop 1 Controller.
The dynamics of the PID
controller will depend on
the value set in this
parameter. See also
21-21 Ext. 1 Proportional
Gain.
NOTE
Always set the desired value for 21-12 Ext. 1 Maximum
Reference before setting the values for the PID controller in
parameter group 20-9*.
21-13 Ext. 1 Reference Source
Option: Function:
This parameter defines which input
on
the frequency converter should be
treated as the source of the reference
signal for the Closed Loop 1
Controller. Analog input X30/11 and
Analog input X30/12 refer to inputs
on the General Purpose I/O.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
21-14 Ext. 1 Feedback Source
Option: Function:
This parameter defines which input
on
the frequency converter should
be treated as the source of the
feedback signal for the Closed Loop
1 controller. Analog input X30/11
and Analog input X30/12 refer to
inputs on the General Purpose I/O.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
123
3 3
