21-53 Ext. 3 Reference Source
Option: Function:
See 21-13
Ext. 1 Reference Source
for
details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[7] Pulse input 29
[8] Pulse input 33
[20] Digital pot.meter
[21] Analog input X30/11
[22] Analog input X30/12
[23] Analog Input X42/1
[24] Analog Input X42/3
[25] Analog Input X42/5
[30] Ext. Closed Loop 1
[31] Ext. Closed Loop 2
[32] Ext. Closed Loop 3
21-54 Ext. 3 Feedback Source
Option: Function:
See 21-14
Ext. 1 Feedback Source
for
details.
[0] * No function
[1] Analog Input 53
[2] Analog Input 54
[3] Pulse input 29
[4] Pulse input 33
[7] Analog Input X30/11
[8] Analog Input X30/12
[9] Analog Input X42/1
[10] Analog Input X42/3
[11] Analog Input X42/5
[100] Bus Feedback 1
[101] Bus Feedback 2
[102] Bus feedback 3
21-55 Ext. 3 Setpoint
Range: Function:
0 ExtPID3Unit* [ par. 21-51 - par. 21-52
ExtPID3Unit]
See
21-15 Ext. 1
Setpoint for details.
21-57 Ext. 3 Reference [Unit]
Range: Function:
0 ExtPID3Unit* [-999999.999 -
999999.999
ExtPID3Unit]
See 21-17 Ext. 1
Reference
[Unit] for
details.
21-58 Ext. 3 Feedback [Unit]
Range: Function:
0 ExtPID3Unit* [-999999.999 -
999999.999
ExtPID3Unit]
See 21-18 Ext. 1
Feedback
[Unit] for
details.
21-59 Ext. 3 Output [%]
Range: Function:
0 %* [0 - 100 %]
See 21-19
Ext. 1 Output [%]
for details.
3.16.8 21-6* Closed Loop 3 PID
21-60 Ext. 3 Normal/Inverse Control
Option: Function:
See 21-20
Ext. 1 Normal/Inverse Control
for details.
[0] Normal
[1] Inverse
21-61 Ext. 3 Proportional Gain
Range: Function:
0.01 * [0 - 10 ]
See 21-21
Ext. 1 Proportional Gain
for details.
21-62 Ext. 3 Integral Time
Range: Function:
10000 s* [0.01 - 10000 s]
See 21-22 Ext. 1 Integral Time
for
details.
21-63 Ext. 3 Differentation Time
Range: Function:
0 s* [0 - 10 s]
See 21-23
Ext. 1 Differentation Time
for details.
21-64 Ext. 3 Dif. Gain Limit
Range: Function:
5 * [1 - 50 ]
See 21-24 Ext. 1 Dif. Gain Limit
for details.
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
MG16H102 - VLT
®
is a registered Danfoss trademark
127
3 3
