0-20 Display Line 1.1 Small
Option: Function:
[1661] Terminal 53 Switch
Setting
Setting of input terminal 53.
Current
= 0; Voltage = 1.
[1662] Analog Input 53 Actual value at input 53 either as a
reference
or protection value.
[1663] Terminal 54 Switch
Setting
Setting of input terminal 54.
Current
= 0; Voltage = 1.
[1664] Analog Input 54 Actual value at input 54 either as
reference
or protection value.
[1665] Analog Output 42
[mA]
Actual value at output 42 in mA.
Use 6-50
Terminal 42 Output to
select the variable to be
represented by output 42.
[1666] Digital Output [bin] Binary value of all digital outputs.
[1667] Pulse Input #29 [Hz] Actual value of the frequency
applied
at terminal 29 as a pulse
input.
[1668] Pulse Input #33 [Hz] Actual value of the frequency
applied
at terminal 33 as a pulse
input.
[1669] Pulse Output #27
[Hz]
Actual value of pulses applied to
terminal
27 in digital output mode.
[1670] Pulse Output #29
[Hz]
Actual value of pulses applied to
terminal
29 in digital output mode.
[1671] Relay Output [bin] View the setting of all relays.
[1672] Counter A View the present value of Counter
A.
[1673] Counter B View the present value of Counter
B.
[1675] Analog In X30/11 Actual value of the signal on input
X30/11
(General Purpose I/O Card.
Option)
[1676] Analog In X30/12 Actual value of the signal on input
X30/12
(General Purpose I/O Card.
Optional)
[1677] Analog Out X30/8
[mA]
Actual value at output X30/8
(General
Purpose I/O Card.
Optional) Use Par. 6-60 to select the
variable to be shown.
[1680] Fieldbus CTW 1 Control word (CTW) received from
the
Bus Master.
[1682] Fieldbus REF 1 Main reference value sent with
control
word via the serial
communications network e.g. from
the BMS, PLC or other master
controller.
[1684] Comm. Option STW Extended fieldbus communication
option
status word.
0-20 Display Line 1.1 Small
Option: Function:
[1685] FC Port CTW 1 Control word (CTW) received from
the
Bus Master.
[1686] FC Port REF 1 Status word (STW) sent to the Bus
Master.
[1690] Alarm Word One or more alarms in a Hex code
(used
for serial communications)
[1691] Alarm Word 2 One or more alarms in a Hex code
(used
for serial communications)
[1692] Warning Word One or more warnings in a Hex
code
(used for serial communi-
cations)
[1693] Warning Word 2 One or more warnings in a Hex
code
(used for serial communi-
cations)
[1694] Ext. Status Word One or more status conditions in a
Hex
code (used for serial communi-
cations)
[1695] Ext. Status Word 2 One or more status conditions in a
Hex
code (used for serial communi-
cations)
[1696] Maintenance Word The bits reflect the status for the
programmed
Preventive
Maintenance Events in parameter
group 23-1*
[1830] Analog Input X42/1 Shows the value of the signal
applied
to terminal X42/1 on the
Analog I/O card.
[1831] Analog Input X42/3 Shows the value of the signal
applied
to terminal X42/3 on the
Analog I/O card.
[1832] Analog Input X42/5 Shows the value of the signal
applied
to terminal X42/5 on the
Analog I/O card.
[1833] Analog Out X42/7
[V]
Shows the value of the signal
applied
to terminal X42/7 on the
Analog I/O card.
[1834] Analog Out X42/9
[V]
Shows the value of the signal
applied
to terminal X42/9 on the
Analog I/O card.
[1835] Analog Out X42/11
[V]
Shows the value of the signal
applied
to terminal X42/11 on the
Analog I/O card.
[2117] Ext. 1 Reference
[Unit]
The value of the reference for
extended
Closed Loop Controller 1
[2118] Ext. 1 Feedback
[Unit]
The value of the feedback signal for
extended
Closed Loop Controller 1
[2119] Ext. 1 Output [%] The value of the output from
extended
Closed Loop Controller 1
Parameter Description
VLT
®
Refrigeration Drive Programming Guide
30 MG16H102 - VLT
®
is a registered Danfoss trademark
33
