Danfoss VLT FC 302 User Manual

Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion index
Type
33-5* I/O Configuration
33-50 Terminal X57/1 digital input [0] No function 2 set-ups TRUE - Uint8
33-51 Terminal X57/2 digital input [0] No function 2 set-ups TRUE - Uint8
33-52 Terminal X57/3 digital input [0] No function 2 set-ups TRUE - Uint8
33-53 Terminal X57/4 digital input [0] No function 2 set-ups TRUE - Uint8
33-54 Terminal X57/5 digital input [0] No function 2 set-ups TRUE - Uint8
33-55 Terminal X57/6 digital input [0] No function 2 set-ups TRUE - Uint8
33-56 Terminal X57/7 digital input [0] No function 2 set-ups TRUE - Uint8
33-57 Terminal X57/8 digital input [0] No function 2 set-ups TRUE - Uint8
33-58 Terminal X57/9 digital input [0] No function 2 set-ups TRUE - Uint8
33-59 Terminal X57/10 digital input [0] No function 2 set-ups TRUE - Uint8
33-60
Terminal X59/1 and X59/2
mode [1] Output 2 set-ups FALSE - Uint8
33-61 Terminal X59/1 digital input [0] No function 2 set-ups TRUE - Uint8
33-62 Terminal X59/2 digital input [0] No function 2 set-ups TRUE - Uint8
33-63 Terminal X59/1 digital output [0] No function 2 set-ups TRUE - Uint8
33-64 Terminal X59/2 digital output [0] No function 2 set-ups TRUE - Uint8
33-65 Terminal X59/3 digital output [0] No function 2 set-ups TRUE - Uint8
33-66 Terminal X59/4 digital output [0] No function 2 set-ups TRUE - Uint8
33-67 Terminal X59/5 digital output [0] No function 2 set-ups TRUE - Uint8
33-68 Terminal X59/6 digital output [0] No function 2 set-ups TRUE - Uint8
33-69 Terminal X59/7 digital output [0] No function 2 set-ups TRUE - Uint8
33-70 Terminal X59/8 digital output [0] No function 2 set-ups TRUE - Uint8
33-8* Global Parameters
33-80 Activated program number -1 N/A 2 set-ups TRUE 0 Int8
33-81 Power-up state [1] Motor on 2 set-ups TRUE - Uint8
33-82 Drive status monitoring [1] On 2 set-ups TRUE - Uint8
33-83 Behaviour after error [0] Coast 2 set-ups TRUE - Uint8
33-84 Behaviour after esc. [0] Controlled stop 2 set-ups TRUE - Uint8
33-85
MCO supplied by external 24 V
DC [0] No 2 set-ups TRUE - Uint8
33-86 Terminal at alarm [0] Relay 1 2 set-ups TRUE - Uint8
33-87 Terminal state at alarm [0] Do nothing 2 set-ups TRUE - Uint8
33-88 Status word at alarm 0 N/A 2 set-ups TRUE 0 Uint16
33-9* MCO Port Settings
33-90 X62 MCO CAN node ID 127 N/A 2 set-ups TRUE 0 Uint8
33-91 X62 MCO CAN baud rate [20] 125 Kbps 2 set-ups TRUE - Uint8
33-94
X60 MCO RS485 serial
termination [0] Off 2 set-ups TRUE - Uint8
33-95
X60 MCO RS485 serial baud
rate [2] 9600 Baud 2 set-ups TRUE - Uint8
Programming Operating Instructions
104 Danfoss A/S © Rev. 2014-07-29 All rights reserved. MG37A202
