Par. No. # Parameter description Default value 4-set-up FC 302
only
Change
during
operation
Conver-
sion
index
Type
5-6* Pulse Output
5-60 Terminal 27 pulse output variable null All set-ups TRUE - Uint8
5-62 Pulse output max freq #27 App.Dependent All set-ups TRUE 0 Uint32
5-63 Terminal 29 pulse output variable null All set-ups x TRUE - Uint8
5-65 Pulse output max freq #29 App.Dependent All set-ups x TRUE 0 Uint32
5-66 Terminal X30/6 pulse output variable null All set-ups TRUE - Uint8
5-68 Pulse output max freq #X30/6 App.Dependent All set-ups TRUE 0 Uint32
5-7* 24V Encoder Input
5-70 Term 32/33 pulses per revolution 1024 N/A All set-ups FALSE 0 Uint16
5-71 Term 32/33 encoder direction [0] Clockwise All set-ups FALSE - Uint8
5-8* I/O Options
5-80 AHF cap reconnect delay 25s 2 set-ups TRUE 0 Uint16
5-9* Bus Controlled
5-90 Digital & relay bus control 0 N/A All set-ups TRUE 0 Uint32
5-93 Pulse out #27 bus control 0.00 % All set-ups TRUE -2 N2
5-94 Pulse out #27 timeout preset 0.00 % 1 set-up TRUE -2 Uint16
5-95 Pulse Out #29 bus control 0.00 % All set-ups x TRUE -2 N2
5-96 Pulse Out #29 timeout preset 0.00 % 1 set-up x TRUE -2 Uint16
5-97 Pulse Out #X30/6 bus control 0.00 % All set-ups TRUE -2 N2
5-98 Pulse Out #X30/6 timeout preset 0.00 % 1 set-up TRUE -2 Uint16
Programming Operating Instructions
82 Danfoss A/S © Rev. 2014-07-29 All rights reserved. MG37A202
66

Danfoss VLT FC 302 Specifications

General

Brake Function	Built-in brake chopper in all units up to 22 kW
Output Voltage Range	0-100% of input voltage
Power Range	0.37 kW
Control Modes	VVCplus, Flux, U/f
Protection Features	Overvoltage, undervoltage, overcurrent, short circuit, overtemperature, overload
Communication Options	Modbus RTU, BACnet, Ethernet/IP, Profinet, Profibus, CANopen, DeviceNet
Ambient Temperature Range	-10°C to +50°C (derating above +40°C)
Enclosure Rating	IP20, IP21, IP55
Cooling Method	Air-cooled
Input Voltage	200-240V, 380-480V, 525-600V
